目前電纜橋架產品發展中出現的問題

    首先，目前的原材料漲價給橋架行業帶來了巨大的沖擊，鋼材、鋁型材、玻璃鋼、鋅錠、粉末涂料等原材料的價格都大幅上揚且有較大波動，而橋架產品的價格上漲幅度遠小于原材料價格上漲的幅度。橋架產品是一種附加值比較低的產品，僅僅是對原材料進行一些簡單的機械加工和表面處理，橋架產品的成本中有相當大的一部分是原材料的成本，幾千元甚至近萬元一噸的單價，加工費用僅僅只有幾百元。生產電纜橋架產品消耗大量的鋼鐵、鋅等自然資源的同時并沒有創造更多的附加價值。
    其次，因為電纜橋架產業的入門門檻較低，電纜橋架的生產工藝簡單，僅僅需要一臺剪板機、一臺折邊機、一臺沖床和幾個工人，就可以生產電纜橋架，導致生產電纜橋架的企業眾多。由于每個企業實力的差別，生產的產品質量水平也不盡相同。然而，由于每個廠生產的產品大同小異，企業為了獲得市場份額大多是采取價格競爭的方法，價格戰讓企業原本就很少的利潤變得更加微薄，于是目前就出現了一些不正常的現象：少數企業為了獲得較高的利潤，就通過降低產品質量的方法來降低成本。以生產鋼制電纜橋架為例：根據承載能力設計要求，需2.0mm 板材生產的，現改用 1.5 mm 板材生產，大跨距橋架幫板需要用 2.5 mm 雙梯幫生產的，現改用 3.0 mm 單梯幫生產；根據使用環境要求，需要進行熱浸鍍鋅表面處理的，現改為價格較低的電鍍鋅或噴涂表面處理，而需要進行電鍍鋅表面處的，JB/T 10216-2000《電控配電用電纜橋架》標準規定橋架構件表面電鍍鋅層厚度應大于或等于12μm，這些企業的產品僅僅做到 3 ～ 4μm。以上行為已經嚴重影響了橋架行業的健康發展，這些都是低價競爭的后果，而眾多的企業又不能夠擺脫打價格戰的命運。

First of all, the current raw material price increases for bridge industry has brought the huge impact, steel, aluminum, glass steel, zinc ingots, powder coatings, etc. Are the price of raw materials rose sharply and there are large fluctuations, and bridge products price rises is far less than the margin of the rising prices of raw materials. Bridge products is a kind of low value-added products, just carry on some simple mechanical processing for raw materials and surface treatment, bridge has a considerable part of the cost of the product is the cost of raw materials, several thousand yuan, even nearly ten thousand yuan a ton of monovalent, processing costs only a few hundred yuan. The production of cable bridge products consumes a lot of natural resources such as steel and zinc without creating additional value.

Second, because of cable tray industry entry threshold is low, cable tray production process is simple, just need a shearing machine, a folding machine, a punch and a few workers, can the production of cable tray, lead to the production of cable tray enterprises. Due to the difference in the strength of each enterprise, the quality level of the products produced is not the same. However, because each factory production products are the same, the enterprise in order to gain market share is mostly adopt the method of price competition, price competition for business already little profit become more thin, so some abnormal phenomena arise at present: a handful of firms in order to obtain higher profits, is to reduce costs by using the method of reduce product quality. In production of steel cable bridge, for example: according to the carrying capacity of the design requirements, should be 2.0 mm plate production, now use 1.5 mm plate production, large span bridge help board need to use 2.5 mm double elevator production, now switch to 3.0 mm single ladder to help production; According to use environmental requirements, the need for hot dip galvanized surface treatment, now changed to lower prices or galvanized coating surface treatment, and the need for electricity galvanized surface, JB/T 10216-2000 "electric distribution with cable tray" standard regulation electric galvanized layer thickness on the surface of the bridge structure should be greater than or equal to 12 microns, the product of the enterprise only do 3 ~ 4 microns. The above behavior has seriously affected the healthy development of the bridge industry, these are the consequences of low price competition, and many enterprises can not get rid of the fate of price war.
